Ray-S

Ray is a refined suspended cylindrical spotlight designed for elegant and focused illumination. Crafted from high-quality extruded aluminum, it ensures durability and efficient heat dissipation. The precision-engineered clear glass and reflector deliver sharp, controlled lighting for a variety of applications.

Suspended from a sleek mounting system, the Ray provides a modern aesthetic, making it ideal for retail, hospitality, and contemporary commercial spaces where both style and performance matter.

  • Electrical
  • Input Voltage - 180 - 280 AC 50Hz
  • Driver Type - Constant Current Driver
  • Control - Switch / DALI / Analog
  • Connection - Plug-in Type Pre-wired
  • General Characteristics
  • Appliance Class - Class 2
  • Ingress Protection - IP20
  • Photobiological Safety - RG 0 - No Risk
  • Ambient Temperature - 0 to +50° C
  • Luminaire
  • Housing Material - Aluminium
  • Environment - Indoor
  • Mounting - Suspended
  • Light Distribution - Direct
  • Body Finish - Aluminium
  • Optics - Clear Glass + Reflector
  • Driver Mount - Integrated
  • Thermal Management - Passive Cooling
  • Light Source
  • LED - Medium Power LED
  • Binning - 3 Step MacAdam
  • Luminous Efficacy - 95 Lm/W
  • Color Temperature - 3000K / 4000K / 5700K
  • CRI - &GreaterEqual≥80 (Standard) &GreaterEqual≥90 (Optional) Tunable LED (Optional)
  • UGR - <19
  • LED Life - >50,000 hours

Lunnark Lighting

Lunnark Lighting

Mounting Size Light Distribution Control CCT Color

Your Selected Product : Ray-S - RY-S-02
